Use the attached image as reference input. Carefully analyze the 2D key plan and extract the exact highway geometry, including all alignments, interchanges (IC-1 to IC-8), rest areas, and the wadi near IC-8. ⚠️ Critical Constraint (Highest Priority): Preserve 100% exact geometry (no modification, no redesign) Maintain identical alignment, curvature, spacing, and proportions Do NOT simplify or reinterpret any interchange or rest area The image is the only source of truth 🔶 Task 1: Full Corridor NIGHT 3D Render (Primary Output) Generate an ultra-realistic NIGHT aerial render of the entire highway corridor from IC-1 to IC-8: Lighting Design (UAE Standard): Main road: 12 m poles, 30–40 m spacing (staggered) LED 150–200W, 4000K روشن uniform lighting (20–30 lux feel) Interchanges: 16–18 m poles + high mast lighting Brighter at merge/diverge zones (50–70 lux feel) Clear hierarchy of lighting intensity Bridges: Linear LED edge lighting Soft under-bridge lighting Rest Areas: Fully lit parking (30–50 lux feel) Warm façade lighting (3000K) Wadi (IC-8): Reduced, environmentally sensitive lighting Minimal light spill, darker natural zone Visual Effects: Night sky (deep blue/black gradient) Realistic light glow and الضوء المنتشر Asphalt reflections Vehicles with headlights and red light trails Atmospheric depth (slight haze) Camera: Wide angled aerial view Entire corridor visible (IC-1 → IC-8) Strong depth showing bridges and layers 🔶 Task 2: Close-Up NIGHT Render – IC-7 Generate a detailed close-up render of IC-7: Exact geometry preserved Complex ramps with clear elevation differences Strong lighting at conflict points Bright nodes + واضح توزيع الإضاءة Vehicles for scale and realism Camera: Medium ارتفاع aerial angle Focus on ramp weaving and bridge crossing 🔶 Task 3: Close-Up NIGHT Render – IC-8 + Wadi Generate a cinematic close-up render of IC-8 including the wadi: Preserve full geometry and wadi alignment Show contrast between infrastructure and natural terrain Lighting: Highway: standard روشن Interchange: brighter Wadi: darker, soft lighting only Visual Effects: Strong contrast (bright roads vs dark desert/wadi) Light trails from vehicles Atmospheric perspective Camera: Cinematic angled aerial Show full interaction (road + interchange + wadi) 🔶 Technical & Quality Requirements Ultra-realistic materials (asphalt, concrete, sand, steel) Accurate engineering proportions (UAE / AASHTO standards) Realistic bridge heights and ramp slopes Resolution: 4K to 8K Clean, sharp, client presentation quality 🔶 Final Instruction This is a strict image-to-3D engineering reconstruction. The result must look like a real built UAE highway project, not conceptual or artistic. If geometry is altered in any way, regenerate until it matches the 2D plan exactly.
