Two-Stage Oxygen Regulator CGA-540 (Medical Grade)
In Stock — Ready to Ship
Precision two-stage pressure regulator for medical oxygen service. Brass and stainless steel construction with a CGA-540 inlet connection. Certified to ISO 4135 and CGA V-1 standards. Ideal for hospital pipeline systems, laboratory applications, and industrial medical gas distribution networks.
$285.00
Configure This Product
Technical Specifications
General
| Gas Service | Oxygen (O₂) |
|---|---|
| Category | Two-Stage Regulator |
| Brand | MGS Professional |
| Model | REG-002-1-CGA540 |
Technical Specifications
| Inlet Connection | CGA-540 |
|---|---|
| Stages | 2 |
| Max Inlet Pressure | 3,000 PSI |
| Outlet Range | 0 – 60 PSI |
| Flow Capacity | 0 – 100 SCFH |
| Body Material | Brass / Stainless Steel |
| Diaphragm | Stainless Steel |
| Seat | PCTFE |
Certifications
| ISO Standard | ISO 4135 |
|---|---|
| CGA Standard | CGA V-1 |
| FDA Compliance | 21 CFR Part 820 |
| CE Marked | Yes |
Dimensions & Weight
| Height | 6.5 in (165 mm) |
|---|---|
| Width | 4.2 in (107 mm) |
| Weight | 2.8 lbs (1.27 kg) |
