HaloGenius Enterprise Architecture (v3.0) Internet │ CDN + WAF + SSL │ API Gateway │ ┌─────────────────────────────────────┐ │ Authentication & Organization │ └─────────────────────────────────────┘ │ ───────────────── Event Bus ───────────────── │ ┌─────────┬──────────┬──────────┬──────────┬──────────┐ │ Voice │ Chat │ Workflow │ CRM │ AI Brain │ │ Service │ Service │ Engine │ Service │ Service │ └─────────┴──────────┴──────────┴──────────┴──────────┘ │ │ │ │ ┌────────┐ ┌────────┐ ┌────────┐ ┌────────┐ │Memory │ │Files │ │Search │ │Billing │ │Service │ │Service │ │Service │ │Service │ └────────┘ └────────┘ └────────┘ └────────┘ Core Microservices (20+) Identity Service Authentication Authorization SSO OAuth JWT MFA Organizations Teams AI Brain Service Responsibilities: LLM Routing Prompt Management Model Selection Token Tracking AI Cost Calculation AI Safety AI Memory Access Supports: OpenAI Gemini Claude DeepSeek Llama Qwen Grok Ollama Voice Service (Dograh) Responsibilities: Phone Calls SIP Twilio Exotel LiveKit STT TTS Voice Streaming Voice Analytics Chat Service Supports: Website Chat WhatsApp Instagram Facebook Telegram Slack Teams SMS Email Workflow Engine (Activepieces) Responsibilities: Execute workflows Schedule jobs Retry failed tasks Human approval Parallel execution Webhooks Event triggers AI nodes CRM Service Leads Contacts Companies Deals Activities Notes Customer Timeline Knowledge Service Document Upload OCR Chunking Embeddings Semantic Search Versioning Source Tracking Memory Service Stores: Conversation Memory Long-term Memory User Preferences Company Context Agent Context Scheduling Service Google Calendar Outlook Zoom Teams Booking Links Reminder Engine Billing Service Stripe Razorpay GST Usage Billing Subscription Plans Credits Invoices Analytics Service Collects: Calls Chats Workflow Runs AI Tokens Revenue Agent Performance Dashboard Metrics Notification Service Channels: Email WhatsApp SMS Push Slack Teams Search Service Global Search across: CRM Calls Chats Documents Workflows AI Employees File Service Storage: Documents Images Audio Videos PDFs Recordings Integration Service 500+ connectors Examples: Salesforce HubSpot Zoho SAP Oracle Shopify Gmail Slack GitHub Notion Marketplace Service Install: AI Employees Templates Workflows Integrations Prompt Packs AI Agent Runtime Every AI Employee runs independently. User ↓ Gateway ↓ Agent Runtime ↓ Planner ↓ Memory ↓ Knowledge ↓ Tool Selection ↓ LLM ↓ Validation ↓ Response AI Planning Layer Each request follows this sequence: Goal ↓ Planning ↓ Task Breakdown ↓ Choose Tools ↓ Execute ↓ Validate ↓ Respond Multi-Agent Collaboration Supervisor AI ├── Sales AI ├── CRM AI ├── Voice AI ├── Finance AI ├── Support AI ├── Scheduling AI └── Knowledge AI Agents communicate through structured events instead of directly calling each other, making the platform easier to scale and debug. Recommended Technology Stack Layer Technology Frontend Next.js 15, React 19, TypeScript UI Tailwind CSS, shadcn/ui, React Flow State TanStack Query, Zustand Backend NestJS, Fastify API REST + GraphQL + WebSockets Workflow Activepieces Voice Dograh + LiveKit AI Orchestration LangGraph AI SDK Vercel AI SDK + LiteLLM Queue BullMQ + Redis Database PostgreSQL Vector DB pgvector or Qdrant Cache Redis Object Storage MinIO or Amazon S3 Search OpenSearch Events NATS or Apache Kafka Observability OpenTelemetry, Prometheus, Grafana, Loki Deployment Docker, Kubernetes, Helm CI/CD GitHub Actions Development Roadmap Phase 1 (MVP) Authentication Voice AI Chat AI Workflow Builder CRM Dashboard Stripe Billing Phase 2 Knowledge Base RAG AI Marketplace Appointment Booking Analytics Integrations Phase 3 Multi-Agent Collaboration AI Supervisor Voice Biometrics Advanced Workflow Templates Enterprise Administration Phase 4 Low-Code App Builder Document Intelligence Vision AI Predictive Analytics AI Process Mining Industry-Specific AI Employees
